SYMBOLS
The following symbols are not relevant to every
vehicle.
Symbols
1
to
9
indicate the subject of each
chapter.
1
General information
2
Specifications
3
Periodic checks and adjustments
4
Engine
5
Cooling system
6
Carburetor
7
Chassis
8
Electrical system
9
Troubleshooting
Symbols
0
to
u
indicate the following.
0
Serviceable with engine mounted
q
Filling fluid
w
Lubricant
e
Special tool
r
Tightening torque
t
Wear limit, clearance
y
Engine speed
u
Electrical data
Symbols
i
to
d
in the exploded diagrams indi-
cate the types of lubricants and lubrication
points.
i
Engine oil
o
Gear oil
p
Molybdenum-disulfide oil
a
Wheel-bearing grease
s
Lithium-soap-based grease
d
Molybdenum-disulfide grease
Symbols
f
to
g
in the exploded diagrams indi-
cate the following.
f
Apply locking agent (LOCTITE
®
)
g
Replace the part
12
34
yu
iop
asd
fg
GEN
INFO
SPEC
CHK
ADJ
ENG
LT
New
COOL
t
r
e
wq
0
9
TRBL
SHTG
8
ELEC
7
CHAS
6
CARB
5
