Yamaha TS-S - Parameter Data Writing

5
Operation
5-39
5.7 Parameterdatawriting
Parameter data is written.
Input
Command Option Command
WIN3 WIN2 WIN1 WIN0
Data Parameter No. 0400h
Output
Command Response Status
WOUT3 WOUT2 WOUT1 WOUT0
- - 0200h
Commandtypeanddata
n
Command (WIN0)
Command Option
Unit
Parameter No. (WIN1) Data (WIN2, WIN3)
0400h
0003h In-position (K3)
Other than TS-P : 0.01mm
TS-P : 0.001mm
0004h Push mode (K4) -
0005h Push judge time (K5) ms
0006h Push speed (K6) 0.01mm/s
0007h ZONE (-) (K7)
Other than TS-P : 0.01mm
TS-P : 0.001mm
0008h ZONE (+) (K8)
Other than TS-P : 0.01mm
TS-P : 0.001mm
0009h Speed override (K9) %
000Ah JOG speed (K10) %
000Bh Inching width (K11)
Other than TS-P : 0.01mm
TS-P : 0.001mm
000Ch MOVE output level (K12) 0.01mm/s
c
CAUTION
The number of write processes is limited since the parameter dada is written into the EEPROM. So, avoid writing
parameter data unnecessarily. Additionally, the write target is a part of operation parameters related to the
positioning operation.
TIP
For parameter data details, see section 4, "Parameter data", in Chapter 3.
n
NOTE
0003h to 0008h, and 000Ch of the writable parameters are available from controller’s software version Ver.1.11.125.
