Yamaha TSX-B235 User Manual

13 En
English
Connect the antenna if you want to listen to the FM/AM (+ P. 3).
[AM radio is available only for North America model.]
 Display information (remote control only)
If you press DISPLAY on the remote control, the information shown on the front panel display will be switched in the
following order.
LISTENING TO FM/AM STATIONS
Selecting an FM/AM station
1 Press the RADIO source button repeatedly to
switch the audio source to FM or AM.
You can also switch the audio source by pressing RADIO on the
remote control.
2 Tuning FM/AM stations.
Automatic tuning: Press and hold TUNING /.
Manual tuning: Press TUNING / repeatedly.
If you tune to a station manually while receiving FM, the sound
will be monaural.
Preset number and frequency
Reception status*
* Examples of reception status indication (the STEREO/MONO
indication is not shown while receiving an AM broadcast).
TUNED/STEREO: A strong FM stereo broadcast is
being received.
TUNED/MONO: A monaural FM broadcast is being
received (even if the FM broadcast is
stereo, reception will be monaural if
the signal is weak).
Not TUNED: No broadcast is being received.
AUX
USB
CD
RADIO
1
2

Yamaha TSX-B235 Specifications

General

Type	Home audio mini system
Cassette deck	No
Product color	White
Disc loading type	Front
Optical disc player	Yes
Number of optical discs	1 discs
Impedance	6 Ω
Bass reflex	-
Speaker type	1-way
RMS rated power	30 W
Number of speakers	2
Total Harmonic Distortion (THD)	10 %
Supported radio bands	AM, FM
Preset stations quantity	30
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Display type	LCD
Bluetooth profiles	A2DP
Audio formats supported	AAC, MP3, WMA
Bluetooth version	2.1+EDR
Power source	AC

Weight and Dimensions

Depth	234 mm
Width	370 mm
Height	110 mm
Weight	3900 g
