9-30
9
19. Install the seat by installing the bolts, and
then tighten the bolts to the specified
torque.
20. Place the rubber damper in the original
position, and then install the center seat
cushion.
EBU32431
Air filter check hoses
There is a check hose at the bottom of the air
filter case (under the cargo bed) and a check
hose at the bottom of the air intake duct (un-
der the vehicle). If dust or water collects in a
check hose, the air filter element may be
soiled. Clean the check hose, air filter element
and air filter case.
1. Cover B
Tightening torque:
Center seat bolt:
23 N·m (2.3 kgf·m, 17 lb·ft)
1. Air filter case check hose
