EBU31389
Multi-function meter unit
The multi-function meter unit is equipped with
the following:
 speedometer
 odometer
 two tripmeters
 clock
 hour meter
 voltage display
 fuel gauge
 error code display
Speedometer
The speedometer shows the vehicle’s travel-
ing speed. The speedometer can be set to
“mph” or “km/h”. This also changes the
odometer and tripmeter units between miles
and kilometers. To change the display be-
tween “mph” and “km/h”, turn the key to “ ”
(off), then while holding the “SELECT” button
pushed, turn the key to “ ” (on).
1. “CLOCK” button
2. “RESET” button
3. “SELECT” button
4. Speedometer
5. Fuel gauge
6. Clock/Hour meter/Voltage display
7. Odometer/Tripmeter A/Tripmeter B/Error code display
3
2
1
4 5
67
