11-1
11
EBU32751
SPECIFICATIONS
EBU38811
The 4-digit model type code can be con-
firmed by checking the model label. (See
page 1-1.)
Dimensions:
Overall length:
3100 mm (122.0 in)
Overall width:
1570 mm (61.8 in) (BHF9, BHFA, BHFB)
1625 mm (64.0 in) (BHFD)
Overall height:
1925 mm (75.8 in)
Wheelbase:
2135 mm (84.1 in)
Ground clearance:
300 mm (11.8 in)
Weight:
Curb weight:
649.0 kg (1431 lb) (BHF9)
652.0 kg (1437 lb) (BHFA, BHFB)
654.0 kg (1442 lb) (BHFD)
Engine:
Combustion cycle:
4-stroke
Cooling system:
Liquid cooled
Valve train:
SOHC
Number of cylinders:
Single cylinder
Displacement:
686 cm³
Bore × stroke:
102.0 × 84.0 mm (4.02 × 3.31 in)
Starting system:
Electric starter
Engine oil:
Recommended brand:
SAE viscosity grades:
5W-30, 10W-30, 10W-40, 15W-40, 20W-40, 20W-50
