2-11
SPEC
Specification
Hull and hood
Part to tightened
Screw
size
Tightening torque See
pageN·mkgf·mft·lb
Upper handlebar cover screw
ø4 1 0.1 0.7 8-1
ø5 1 0.1 0.7 8-1
Lower handlebar cover screw ø6 4 0.4 3.0 8-1
Grip end bolt M5 1 0.1 0.7 8-2
Left handlebar switch assy. screw ø5 3 0.3 2.2 8-2
Throttle lever assy. bolt M5 3 0.3 2.2 8-2
Handlebar holder bolt M8 20 2 14.8 8-2
Mirror nut — 70.75.28-8
Hood lock bolt M5 4 0.4 3.0 8-8
Front hood screw ø5 2 0.2 1.5 8-8
Hinge nut — 70.75.28-8
Hinge bolt M6 7 0.7 5.2 8-8
Engine hatch cover nut — 50.53.78-11
Engine hatch cover bolt M6 5 0.5 3.7 8-11
Multifunction meter screw ø5 4 0.4 3.0 8-11
Steering cable stopper bolt M6 7 0.7 5.2 8-13
Steering master assy. bolt M8 17 1.7 12.5 8-13
Steering arm assy. bolt M8 16 1.6 11.8 8-13
Ball joint nut — 70.75.28-14
Ball joint — 70.75.28-14
Buzzer bracket bolt M5 4 0.4 3.0 8-14
Case assy. bolt M6 7 0.7 5.2 8-14
Steering cable locknut — 70.75.28-16
Packing nut — 5.9 0.59 4.4 8-16
Seat lock assy. bolt M6 6 0.6 4.4 8-18
Projection nut — 26 2.6 19.2 8-18
Handgrip nut — 50.53.78-18
Seat holder nut — 15 1.5 11.1 8-19
Cooling water pilot outlet nut — 40.43.08-19
Water lock/rubber hose clamp — 50.53.78-23
Exhaust outlet/rubber hose clamp — 50.53.78-23
Exhaust outlet/Exhaust outlet bolt 5 0.5 3.7 8-23
Bow eye bolt M6 13 1.3 9.6 8-25
Front protector nut — 70.75.28-25
Sponson bolt M8 15 1.5 11.1 8-25
Ski tow nut — 15 1.5 11.1 8-27
Spout hose clamp — 20.21.58-27
Spout nut — 50.53.78-27
Stern eye nut — 15 1.5 11.1 8-27
Drain plug nut — 20.21.58-27
