Yamaha WaveRunner VX 700 Service Manual

4-1
FUEL
Fuel system
Fuel cock and fuel filter
No. Part name Q’ty Remarks
1Screw 1 M4 × 7 mm
2 Fuel cock knob 1
3Nut 1
4 Washer 1
5 Fuel cock assy. 1
6 Fuel hose 3
7 Holder 1
8 Fuel filter 1
9 Fuel hose 1
1
2
7
8
9
3
4
5
6
(OUT)
(ON)
(RES)
2 N • m (0.2 kgf • m, 1.5 ft • Ib)
5 N • m (0.5 kgf • m, 3.7 ft • Ib)

Yamaha WaveRunner VX 700 Specifications

General

Model	WaveRunner VX 700
Displacement	701cc
Fuel Capacity	13.2 gal
Rider Capacity	3
Width	46.1 inches
