Yamaha WaveRunner VX 700 Service Manual

5-16
1
2
3
4
5
6
7
8
9
A
Cylinder head
No. Part name Q’ty Remarks
Exhaust chamber assy. See “Exhaust chamber assy.” (5-11).
1Bolt 2 M6 × 16 mm
2 Thermoswitch 1
3 Spark plug 2
4Bolt 10 M8 × 50 mm
5 Cylinder head 1
6Gasket 1
25 N
·
m (2.5 kgf
·
m, 18.4 ft
·
Ib)
15 N
·
m (1.5 kgf
·
m, 11.1 ft
·
Ib)
29 N
·
m (2.9 kgf
·
m, 21.4 ft
·
Ib)
1
2
4
3
5
6
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
Reed valves / Cylinder head
