Yamaha YW50AP User Manual

6-12
CHAS
FRONT BRAKE
Order
1
2
3
4
5
6
7
Q’ty
1/1
1
1
2
1
1
1
MASTER CYLINDER
Remarks
Remove the parts in order.
Refer to “BRAKE FLUID REPLACE-
MENT” section in CHAPTER 3.
Refer to “MASTER CYLINDER INSTAL-
LATION” section.
Reverse the removal procedure for in-
stallation.
Job name/Part name
Master cylinder removal
Drain the brake fluid
Brake lever/compression spring
Brake switch
Union bolt
Copper washer
Brake hose
Master cylinder bracket
Master cylinder
New
T
R
.
.
9Nm(0.9 m.kg, 6.5 ft.lb)
T
R
.
.
20Nm(2.0 m.kg, 14 ft.lb)
LS
1
2
5
4
7
3
6
