INSP
ADJ
3-6
ENGINE
IDLE SPEED ADJUSTMENT
1. Remove
8 Battery box cover 1
ENGINE IDLE SPEED ADJUSTMENT
1
1
1
2. Start the engine and let it warm up.
w
Before starting the engine, be sure to use the
centerstand for safety.
3. Attach:
8 Inductive tachometer 1
To the spark plug lead
Inductive tachometer:
YU-8036-A
4. Check:
8 Engine idle speed
Out of specification→Adjust.
Engine idle speed:
1,750~1,850 r/min
5. Adjust:
8 Engine idle speed
***************************************
Adjustment steps.
8 Turn the throttle stop screw 1 in or out until
specified idle speed is obtained.
Turn in Idle speed becomes higher.
Turn out Idle speed becomes lower.
***************************************
To Next Page
