SPEC
2-8
TIGHTENING TORQUES
CHASSIS
Tightening
torque
Nm m•kg ft•lb
Thread
size
Remarks
Part to be tightened
8.4
4.5
1.3
3.0
1.6
2.2
4.3
2.0
1.0
0.7
0.4
0.7
0.7
0.2
0.7
7.0
12.0
1.0
2.3
2.0
2.3
0.6
Frame and engine bracket
Engine bracket, compression rod and engine
Rear carrier
Rear shock absorber and frame
Rear shock absorber and engine
Steering ring nut
Handle holder and steering shaft
Brake hose and master cylinder
Fuel tank
Fuel cock
Fuel sender
Box
Seat lock assembly
Plastic parts & cover
Footrest board
Front wheel axle and nut
Rear wheel axle and nut
Rear brake cam lever
Front brake caliper and front fork
Brake disc and hub
Brake hose and caliper
Brake caliper and bleed screw
M 12
M 10
M 6
M 10
M 8
M 25
M 10
M 8
M 6
M 6
M 5
M 6
M 6
M 5
M 6
M 10
M 14
M 6
M 8
M10
M 8
M 5
84
45
13
30
16
22
43
20
10
7
4
7
7
2
7
70
120
10
23
20
23
6
See
”page3-18”
MAINTENANCE SPECIFICATION
61
31
9.4
22
12
16
37
14
7
5.1
2.9
5.1
5.1
1.4
5.1
51
87
7.2
16.6
14.5
16.6
4.3
