6-22
CHAS
REAR WHEEL AND REAR BRAKE
Order
1
2
3
4
5
6
7
8
Q’ty
1
1
1
1
1
1
1
1
Remarks
Reverse the removal procedure for in-
stallation.
Job name/Part name
Adjuster
Brake cable
Pin
Return spring
Brake shoe
Camshaft lever
Wear indicator
Brake camshaft
T
R
.
.
10Nm(1.0 m.kg, 7.2 ft.lb)
New
5
8
2
4
1
3
7
6
REAR BRAKE
LS
LS
