Yamato SM310 - 15 Replacement Parts List

44
Replacement Parts List
Common for all SM series
Part Name Part No. Specifications
Planar Board 1-24-000-0059 ⅣCR
PIO Board 1-24-000-0028 ⅣFR
Power Board 1-24-000-0026 ⅣCR
SSR1 (SM300) 2-16-000-0020 YLT-SSR-01A
SSR2 (SM300) 2-16-000-0021 YLT-SSR-01B
SSR (SM200/310/510) 2-16-000-0010 YLT-SSR-01
CPU 1-18-001-0006
Transformer(Tr1; SM200/300) 2-18-000-0035 AD21-100A 115V
Transformer(Tr2; SM200/300) 2-18-000-0022 AC100V
Transformer(Tr1; SM310/510) 2-18-000-0035 AD21-100A 220V
Transformer(Tr2; SM310/510) 2-18-000-0023 AC200V
Relay (SM200/310/510) 2-05-000-0031 LY2F-DC12V
Relay (SM300) 2-05-000-0019 HEla-DC12V
Relay 2-05-012-0001 JRlaF-TM-DC12V
Stick Keypad SM51A-30490 W467
Current Transformer 2-17-001-0002 URP CTL-6-5-400
Pressure Relief Switch 2-01-001-0014 A2A-4W
Circuit Breaker (SM200/310/510) 2-06-001-0003 BS2021
Circuit Breaker (SM300) 2-06-001-0004 BS2022
Heater 1 (SM200) 2-24-000-0057 AC115V 1.3kw
Heater 1 (SM300) 2-24-000-0058 AC115V 1.7kw
Heater 1 (SM310/510) 2-24-000-0059 AC220V 2.0kw
Heater 2 (SM200) 2-26-000-0003 AC115V 500W
Heater 2 (SM300/310/510) 2-26-000-0004 AC115V 750W
Sensor 1 1-16-003-0035 Pt100 Resistance Thermometer Sensor
Sensor 2 1-16-003-0034 T type Thermometer
Solenoid Exhaust Valve (SM200/300) 3-02-001-0016 AB41-02-7-C4A PT1/4 AC100V CKD
Solenoid Exhaust Valve (SM310/510) 3-02-001-0017 AB41-02-7-C4A PT1/4 AC200V CKD
Solenoid Drain Valve (SM200/300) 3-02-001-0016 AB41-02-7-C4A PT1/4 AC100V CKD
Solenoid Drain Valve (SM310/510) 3-02-001-0017 AB41-02-7-C4A PT1/4 AC200V CKD
Micro Switch 2-02-001-0005 ABV163661
Safety Valve (SM200) 3-18-001-6003 M3D-B1.6±0.2Kgf/cm
2
Safety Valve (SM300/310/510) 3-18-001-6002 M3D-B2.0±0.2Kgf/cm
2
Plug SM500-30280
Silencer SM500-30340
Lid Gasket (SM200) 241022-180 SH75UN
Lid Gasket (SM300/310/510) 241024-180 SH75UN
Bottom Plate (SM200) SM200-30750
Bottom Plate (SM 300/310/510) SM500-30750
Filter SM500-30700
Drain Valve 3-15-0003-6002 Type BSB PT3/8
Mesh (WG)253003-172-2
Bottle 7-26-000-0006 5000cc
Pressure Gauge 5-05-000-0002 GS58-201
●The solenoid valve is usable for exhaust band drain.
