17
e. Chip protection
The lathe is provided with a protective cover for the tool cutting chip.
f. securing screw
Tighten the securing screw at the end of the lathe bed in order to
prevent the tailstock from unintentional drawing-out of the lathe bed.
positions switch
Chip protection closed Chip protection opened
Integrated position switch
