11
43. Never mount the workpiece too large or heavy toward the lathe.
44. Never mount the workpiece too large or heavy toward the operator.
45. Use necessary tools to treat the workpiece.
46. Never apply excessive force on the attachment or the operation
lever.
47. Take care to jig the workpiece firmly.
48. Tighten all claws, nuts, screws and fasteners.
49. Always take care to use correct equipment.
50. Never make cutting beyond the ability of the lathe.
51. Do not apply excessive force to polish or to deburr.
52. Always take care to adopt suitable tool to deburr. Do not deburr in a
hurry and take care of burrs on the chuck and the workpiece.
53. Switch off power supply to stop all movements of the lathe before
replacing the exchange gears.
54. Take care if the chuck/parts could drop down when the lathe is in
operation.
1-4 Protection of the Chuck
The lathe is equipped with the guard of the chuck (option), which is
suitable for the standard chuck.
In case the chuck guard is equipped on the lathe, it should be in a
closed status before the spindle is running.
1) When the machine is equipped with larger chuck, the chuck guard
should be replaced with one which has corresponding diameter with that
of the chuck.
It is suggested that claws cannot extend out the outer diameter of the
chuck in order to avoid bump with the chuck guard. For the sake of safe
operation, always take care not to extend claws out of the outer diameter
of the chuck.
2) When the face chuck is used, the chuck guard should be removed. If
Instructions Manual for CL-38 (L190)
