15.3 Electric Listing Component
No. Type Name Specification Qty
1 SA High/Low/Stop Switch LW8PS-25/M10T 1
2 SA0 Main Switch LW8GS-25/30000-A 1
3 QM1 Breaker GV2 2.5-4A 1
4 QM2 Breaker DZ451-63 2P C1 1
5 QM3 Breaker DZ451-63 1P C5 1
6 QM4 Breaker DZ451-63 1P C2 1
7 FR1 Thermal overload relay 3UA5940 6.3-10A 1
8 FR2 Thermal overload relay 3UA5940 0.4-0.63A 1
9 KM1,2 AC Contactor 3TB4122 AC24V 50/60Hz 2
10 KA0 Relay 3TH8262 AC24V 50/60Hz 1
11 KA1 Relay 3TH8262 AC24V 50/60Hz 1
12 TC Control Transformer JBK5-160 1
13 KT Time Relay ST3PA AC24V 1
14 VA Rectifier 3TQL 250V 12A 1
15 HL Pilot Lamp LA103-M/32 AC24V 1
16 EL Working Lamp JC34A AC24V 1
17 SQ4,5 Switch For FWD-REV LXW5-11G2 2
18 SQ1 Switch For Brake LXW5-11N1 1
19 SQ2 Switch For Chuck LXW5-11Q1 1
20 SQ3 Switch For Position QKS8-6080103201 1
21 SB0 Emergency Button LA103-01ZS/1 1
22 SB1 Button LA103-10/3 1
23 SB2 Button LA103-10X/3 1
24 M1 Main Motor YD132M2-8/4 1
25 M2 Coolant Pump AB25 1
