19
3. Specification
Capacity
Swing Over Bed 360mm(14") or 410mm(16")
Swing Over Cross Slide 215mm(81/2") or 255mm(10")
Swing In Gap Diameter×Width 540(211/4") or 580(23")×190(71/2")
Height of Center 185mm(71/2") or 205mm(8")
Distance Between Centers 1000mm(40")/1500 mm
Width of Bed 250mm(10")
Cutting Tool Max Section 20×20mm(3/4"×3/4")
Total Travel of Cross Slide 210mm(81/2")
Total Travel of Top Slide 140mm(51/2")
Headstock
Spindle Bore 52mm(2")
Spindle Nose D1-6
Spindle Morse Taper in Bore M.T.No. 6
Spindle Speeds Number 16
Spindle Speeds Range 45-1800R.P.M
Thread & Feeds
Leadscrew Diameter & Thread 28mm×6mm or 4T.P.I
Threads Imperial Pitches 2-72T.P.I(45Nos)
Threads Metric Pitches 0.2-14mm(39Nos)
Longitudinal Feeds Imperial 0.002"-0.067"/Rev (17Nos)
Longitudinal Feeds Metric 0.05-1.7mm/Rev (17Nos)
Cross Feeds Imperial 0.001"-0.0335"/Rev (17Nos)
Cross Feeds Metric 0.025-0.85mm/Rev (17Nos)
Range of Module Pitches 0.3-3.5MP(18Nos)
Range of Diametral Pitches 8-44DP(21Nos)
Tailstock
Total Travel of Tailstock Quill 120mm(43/4")
Tailstock Quill Diameter 50mm(2")
Taper in Tailstock Quill M.T.No.4
Motors
Spindle Drive Motor 4P/8P, 3PH 3.3/2.2kw or 4.5/3kw
Coolant Pump Motor 4P, 3PH 90W
Weight & Measures
Machine Space Requires (L×W×H) 194（244）cm×85cm×130cm or132cm
Packing Case Dimensions (L×W×H) 206 (81")×90 (35
7
/
16
")×164cm(64
9
/
16
")
Net Weight 1300kg or 1350kg/1550kg or 1600kg
Gross Weight 1500kg or 1555kg/1750kg or 1755kg
Instructions Manual for CL-38 (L190)
