faceplate and re-adjust the stud as indicated in the illustration. Fit and
tighten the locking screw (B) at each stud before remounting the
chuck for work. A reference mark should be made on each correctly
fitted chuck or faceplate to coincide with the reference mark scribed
in the spindle nose. This will assist subsequent remounting.
IMPORTANT: Do Not Interchange Chucks or Face Plates Between
Lathes Without Checking For Correct Cam Locking.
Instructions Manual for CL-38 (L190)
