36
No. Part No. Name Specification
40 CD6236-01-41 Nut
41 CL6132-06-11 Plug
42 GB117-86 Taper Pin 5×45
43 GB894.2-86 External circlip 28
44 CD6236-01-36 Feed Rod
45 CD6236-01-38 Sleeve
46 GB301-84 Thrust Bearing 8103
47 CD6236-01-40 Sleeve
48 GB77-85 Set Screw M12×8
49 GB2089-80 Spring 1×9×20
50 GB308-84 Steel Ball 9.5
51 CD6236-01-55 Sleeve
52 CD6236-01-29 Clutch
53 GB308-84 Steal Ball 8
54 GB2089-80 Spring 1.2×6×46
55 GB77-85 Screw M10×10
56 CD6236-01-35 Started Rod
57 GB77-85 Screw M8×8
58 CD6236-01-23 Lever
59 CD6236-01-21 Pin
60 GB896-86 Circlip 6
61 GB117-86 Taper Pin 6×50
62 GB70-85 Socket Head Cap Screw M8×35
63 GB80-85 Screw M8×14
64 GB1171-74 V13-1890
65 RUN6141-106028 Cover
66 GB818-85 Cross Screw M6×10
67 RUN6246-108078 Limited Switch Seat
68 GB70-85 Socket Head Cap Screw M6×16
69 RUN6141-106028-01 Cover
70 GB818-85 Cross Screw M6×10
71 CD6236-01-01A Stand
72 RUN6246-106033 Cover
73 GB818-85 Cross Screw M6×10
74 GB818-85 Screw M4×30
75 CD6236-01-59 Limited Switch Seat
76 GB6172-86 Nut M4
77 GB70-85 Socket Head Cap Screw M8×30
78 RUN6141-106049a Washer
79 CD6236-01-05 Belt Pulley
Instructions Manual for CL-38 (L190)
