YANGZHOU SUPER MACHINE TOOL CD6240 - Page 39

39
No. Part No. Name Specification
1 CL6132-04-77 Nut
2 CD6236-04-72 Cover(360)
2 CD6240-04-72 Cover(410)
3 GB900-88 Bolt M10×85
4 GB70-85 Socket Head Cap Screw M8×16
5 CD6240-05-02 Washer
6 CD6240-04-53G1 Change Gear Metric(33T)
6 CD6236-04-53 Change Gear(360) Inch(24T)
6 CD6240-04-53 Change Gear(410) Inch(24T)
7 GB893.1-86 Circlip 47
8 GB279-88 Roller Bearing 160105
9 CD6240-05-10 Swing France
10 CD6236-05-06 Sleeve
11 CD6236-05-05 Shaft
12 GB6172-86 Nut M14
13 GB97.1-84 Washer 14
14 CD6240-05-09G1 Change Gear Metric(35/48T)
14 CD6236-05-09 Change Gear(360) Inch(44/52T)
14 CD6240-05-09 Change Gear(410) Inch(44/52T)
15 GB41-76 Nut M14
16 CD6236-01-44 Washer 45
17 CD6236-01-43 Screw
18 CD6236-05-03 Sleeve
19 CD6240-05-04G1 Change Gear Metric(54T)
19 CD6236-05-04 Change Gear(360) Inch(57T)
19 CD6240-05-04 Change Gear(410) Inch(57T)
20 CD6236-01-24 Bolt
21 GB54-76 Nut M10
22 CD6236-04-71 Plate
23 GB818-85 Screw M3×8
04/03/2020
Instructions Manual for CL-38 (L190)
39
