68
No. Part No. Name Specification
1 CD6236-07-49A Bush(S-Post)
1 CD6236-07-49 Bush(T-Post)
2 GB2089-80 Spring 0.5×5×18
3 CD6236-07-50 Pin
4 CD6236-07-21 Tool Post
5 GB98-83 Screw M10×50
6 CD6236-07-29 Clamp Handle
7 CD6236-07-19 Clamping Handle
8 CD6236-07-20 Washer
9 CD6236-07-18A Tool Post Shaft(S-Post)
9 CD6236-07-18 Tool Post Shaft(T-Post)
10 GB1155-79 Ball Cup 6
11 CD6236-07-25A Compound Rest(360S-Post)
11 CD6240-07-25A Compound Rest(410S-Post)
11 CD6236-07-25 Compound Rest(360T-Post)
11 CD6240-07-25 Compound Rest(410T-Post)
12 CD6236-07-17G Nut(Metric)
12 CD6236-07-17 Nut(Inch)
13 CD6236-07-07G Feed Screw(Metric)
13 CD6236-07-07 Feed Screw(Inch)
14 GB77-85 Screw M8×8
15 CD6236-07-46 Bottom
16 GB1096-79 Key 4×12
17 GB301-84 Thrust Bearing 8101
18 GB2089-80 Spring 0.5×5×18
19 GB308-77 Steel Ball 6
20 CD6236-07-13 Seat
21 GB70-85 Screw M6×20
22 CD6236-07-12G Steel Ball(Metric)
22 CD6236-07-12 Steel Ball(Inch)
23 CD6236-07-11G Dial-Compound Rest(M)
23 CD6236-07-11 Dial-Compound Rest(Inch)
24 CD6236-07-10 Handle
25 GB70-85 Screw M10×25
26 CD6236-07-05 Handle
27 CD6236-07-06 Handle
28 CD6236-07-08 Screw Plug
29 GB77-85 Screw M6×8
30 CD6236-07-26 Swivel Table(360)
30 CD6240-07-26 Swivel Table(410)
Instructions Manual for CL-38 (L190)
