No. Part No. Name Specification
67 GB77-85 Screw M8×20
68 CD6240-07-63a Gear Shaft Mn=1.5 Z=16
69 CD6236-07-40 Screw
70 CD6236-07-39 Handle Spacer
71 CD6236-07-15 Plug
72 CD6236-07-34 Wiper Cover
73 CD6236-07-33 Wiper
74 CD6236-07-04 Clamp Screw
75 GB70-85 Screw M6×20
76 CD6236-07-32 Wiper Cover
77 GB818-85 Screw M5×16
78 GB1096-86 Key 3×3×20
79 CD6236-07-31 Wiper
80 CD6236-07-28 Carriage
81 GB77-85 Screw M6×8
82 CD6236-07-61 Shaft
83 CD6236-07-60 Gear Mn=1.5 Z=25
84 CD6236-07-59 Washer
85 GB70-85 Screw M5×10
86 CD6236-07-03 Support Screw
87 CD6236-07-02 Clamp Block
88 CD6236-07-16 Gib
89 CD6236-07-58 Gib
90 CD6236-07-57 Gib
91 GB68-85 Screw M4×6
92 GB70-85 Screw M6×20
93 CD6236-07-16-1 Baffle
94 CD6236-07-56 Gib
