No. Part No. Name Specification
1 CD6236-07-01 13/13 Proper Screw
2 GB97.1-85 Washer 10
3 CD6236-07-01 10/13 Distributor
4 GB77-85 Screw M4×5
5 15326C Tie-in
6 Lubrication Tube φ5
7 2143SC Tie-in φ5/Z1/8
8 CD6236-07-01 6/13a Pump
9 GB308-77 Ball 5
10 GB2089-80 Spring 0.5×4×15
11 GB3452.1-82 O-Ring 11.2×1.8
12 CD6236-07-01 5/13 Plug
13 Lubrication Tube φ5
14 CD6236-07-01 7/13 Joint
15 GB2089-80 Spring 1×7×45
16 GB3452.1-82 O-Ring 8×2.65
17 CD6236-07-01 2/13 Piston
18 CD6236-07-01 4/13 Plate
19 GB819-85 Screw M5×12
20 CD6236-07-01 3/13 Name Plate
21 GB67-85 Screw M5×15
22 RUN6241-103067 Knob
23 22587T Tie-in φ6/Z1/8
24 Lubrication Tube φ6×150
25 RUN6246-103071 Tie-in
26 RUN6246-103072 Nut
27 B1061C Double Taper Sheath 4
28 RUN6246-103073 Valve
