74
No. Part No. Name Specification
1 GB78-85 Key 5×25
2 CD6236-08-16 Screw Plug
3 CD6236-08-17 Hand Wheel
4 GB2089-80 Spring 0.6×5×16
5 GB308-84 Steel Ball Φ6.5
6 GB894.1-86 Retaining Ring 32
7 GB301-84 Thrust Bearing 8104
8 CD6236-08-13 Bracket
9 GB1096-79 Key 5×16
10 CD6236-08-18 Bolt
11 CD6236-08-19 Handle
12 CD6236-08-14 Dial
13 CD6236-08-15 Retaining Ring
14 GB70-85 Screw M5×25
15 CD6236-08-11 Feed Screw
16 GB1155-79 Oil Cup 8
17 CD6236-08-01 Tailstock
18 GB70-85 Screw M6×16
19 CD6236-08-12 Feed Nut
20 CD6236-08-10
Quill
21 GB55-76
Hexagon Thick Nut
M12
22 GB97-85 Washer 12
23 GB827-85 Button Head Rivet 2×8
24 CD6236-08-26 Set-Over Indication Chart
25 CD6236-08-05 Tail Stock Base
26 CD6236-08-25 Bedway Wiper
27 GB818-85 Cross Screw M4×10
28 CD6236-08-27 Bedway Wiper Plate
29 GB97.1-86 Washer 10
30 GB93-85 Spring Washer 10
31 GB5780-86 Bolt M10×45
32 CD6236-08-29 Clamping Block
33 GB5780-86 Bolt M12×110
34 GB5780-86 Bolt M12×80
35 GB95-86 Washer 12
36 CD6236-08-06 Clamping Block
37 CD6236-08-20 Adjusting Block
38 CD6236-08-30 Washer
39 CD6236-08-04 Screw
40 CD6236-08-03 Gib
