YANGZHOU SUPER MACHINE TOOL CD6240 - Page 77

77
No. Part No. Name Specification
1 GB70-85 Screw M6×12
2 GB93-86 Washer 6
3 CD6236-04F-02
Support Bracket
4 CM6233-F1005 Sleeve
5 GB75-85 Screw M8X20
6 CD6236-04FA-01 Cover
7 HY8315.4 A=114 handle
8 GB78-85 Screw M6×10
9 RIN6236-101101 Cover Bracket
10 CD6236-04FA-04 Shaft
11 GB78-85 Screw M8×10
12 GB70-85 Screw M6×10
04/03/2020
Instructions Manual for CL-38 (L190)
77
