No. Part No. Name Specification
1 RUN6246-110019 Rotate Handle
2 GB78-85 Screw M6×8
3 RUN6246-110004 Bush
4 CD6236-10-11 Screw Shaft
5 CD6236-10-10 Sleeve
6 GB77-85 Screw M6×6
7 CD6236-10-09 Follow Rest
8 GB879-86 Spring Pin 5×26
9 RUN6246-110018 Limited Screw
10 CD6236-10-08 Support Shaft
11 GB119-86 Pin 6×16
12 GB278-88 Bearing 80026
13 GB5782-86 Bolt M10×40
14 GB97.1-86 Washer 6×16
