81
No. Part No. Name Specification
1 RUN6246-110019 Rotate Handle
2 GB78-85 Screw M6×8
3 RUN6246-110004 Bush
4 CD6240-10-05 Screw Shaft
5 CD6236-10-04 Sleeve
6 GB77-85 Screw M6×6
7 RUN6246-110014 Handle
8 CD6236-10-02 Upside of Steady Rest
9 RUN6246-110013 Clamping Screw
10 GB119-86 Pin 10×50
11 GB879-86 Spring Pin 5×32
12 GB119-86 Pin 6×20
13 CD6240-10-07 Guard Bush
14 CD6236-10-01 Dowmside of Steady Rest
15 GB119-86 Pin 10×50
16 RUN6246-110018 Limited Screw
17 GB6170-86 Nut M16
18 GB97.1-86 Washer 16
19 CD6240-10-03 Clamping Bracket
20 GB5780-86
Bolt
M16×80
21 CD6236-10-06
Support Shaft
22 GB278-88 Bearing 80026
04/03/2020
Instructions Manual for CL-38 (L190)
81
