84
No. Part No. Name Specification Qty
1 CD6240-20-02 Chip Cover 1
2 CD6240-20-09 Clamp 1
3 GB70-85 Screw M4×10 21
4 GB97.1-85 Washer 4 18
5 CD6240-20-07 Chip Cover 1
6 CD6240-20-03 Chip Cover Plate 1
7 CD6240-20-06 Chip Cover Fixing Plate 1
8 GB80-85 Screw M6×6 5
9 CD6240-20-05 Shaft 1
10 CD6240-20-03 Top Cover Plate Select Purchase 1
11 CD6240-20-01 Main Block 1
12 CD6240-20-04 Lock for Switch Stop 1
13 GB70-85 Screw M6×20 1
14 GB70-85 Screw M6×16 3
15 CD6240-20-02 Chip Cover Plate 1
16 Switch 1
17 GB70-85 Screw M4×30 2
