TROUBLESHOOTING
JH Series Operation Manual 145
Engine-ECU
EMG STP - - - - Emergency Stop - - - - - Digital Display (VC10)
AUX STP - - - - Emergency Stop - - - - - LCD (B25, C35))
COM ERR - - - - Communication error between
panel and engine ECU
-----
Suspicious Loose
connection of Extention
harness.
Suspicious blown
fuse(20A/ECU).
Drive-ECU
- P0920 773 3 - SHIFT FORWARD H RANGE - - - - -
- P0920 773 4 - SHIFT FORWARD L RANGE - - - - - Shift Valve (F) shuts off
- P0924 784 3 - SHIFT REVERSE H RANGE - - - - -
- P0924 784 4 - SHIFT REVERSE L RANGE - - - - -
- P0745 740 3 - CHANGE VALVE H RANGE - - - - -
- P0745 740 4 - CHANGE VALVE L RANGE
-----
Trolling function come to
be unavailable
- P0720 191 8 - PROP SPEED SENSOR L
RANGE
-----
C-type trolling functionis
switched E-type
- P0218 177 0 - GEAR OIL TEMP TOO HIGH
-----
Trolling function come to
be unavailable
- P0710 177 3 - GEAR OIL TEMP H RANGE - - - - -
- P0710 177 4 - GEAR OIL TEMP L RANGE - - - - -
- U103 525 10 - CAN COM ERROR
-----
Shift is changed to
Neutral position
- U100 190 10 -
CAN COM ERROR ENGINE SPEED
-----
- U404 525 2 - CAN COM ERROR SHIFT
-----
Shift is changed to
Neutral position
- U402 684 2 - CAN COM ERROR TROLLING
-----
Trolling function come to
be unavailable
- P0560 158 1 - BATTERY VOLTAGE TOO LOW - - - - -
- C1010 521238 3 - Tank1 level sensor HI range - - - - -
- C1010 521238 4 - Tank1 level sensor LO range - - - - -
- C1011 521239 3 - Tank2 level sensor HI range - - - - -
- C1011 521239 4 - Tank2 level sensor LO range - - - - -
- C1051 521240 3 - Rudder angle sensor HI range - - - - -
- C1051 521240 4 - Rudder angle sensor LO range - - - - -
- C1012 521994 13 - Tank1 level calibration error - - - - -
- C1013 521995 13 - Tank2 level calibration error - - - - -
- C1052 521996 13 - Rudder angle calibration error - - - - -
- P1070 521243 3 - Seawater temperature sensor HI
range
-----
- P1070 521243 4 - Seawater temperature sensor LO
range
-----
- P0070 171 3 - Outside air temperature sensor HI
range
-----
- P0070 171 4 - Outside air temperature sensor LO
range
-----
- C1014 521997 13 - Seawater temperature calibration
error
-----
- C1015 521998 13 - Outside air temperature calibration
error
-----
- U2003 521233 4 - House battery voltage LO range - - - - -
- P0840 127 3 - Gear oil pressure sensor HI range - - - - -
- P0840 127 4 - Gear oil pressure sensor LO range - - - - -
- P1628 630 12 - Drive ECU EEPROM error - - - - -
- P0605 628 12 - ROM CRC abnormality - - - - -
- P1826 522017 6 - Trolling solenoid over current
failure
-----
Trolling feature will be
unavailable.
- P1827 522017 5 - Trolling solenoid non current
failure
-----
Trolling feature will be
unavailable.
LCD DTC SPN FMI
With
FFD
DTC Description
Failsafe Action
Level
1
Level
2
Level
3
Level
4
ENG
Stop
Note
