TROUBLESHOOTING
146 JH Series Operation Manual
Helm-ECU
- U100 523760 9 - CAN COM ERROR ENG-ECU TO
HELM-ECU
--- -
Station change comes to
be unavailable
- U404 523761 9 - CAN COM ERROR DRIVE-ECU
TO HELM-ECU
--- -
Shift change comes to
be unavailable
- U1201 523762 9 - CAN COM ERROR HELM-ECU
TO HELM-ECU
--- -
Station change comes to
be unavailable
- U1202 523763 9 - CAN COM ERROR HELM-LOCAL
--- -
Station change, Synch.
Operation, Warmup
operation, and Engine
speed limit mode come
to be unavailable
- B1001 523543 4 - NEUTRAL SW ACTIVATED
-----
Station change, Synch.
Operation, Warmup
operation, and Engine
speed limit mode come
to be unavailable
- B1002 523542 4 - SELECT SW ACTIVATED
-----
Station change and
Indicator dimming
operation come to be
unavailable
- B1003 523544 4 - SYNCHRO SW ACTIVATED
-----
Station change and
Synchronization feature
come to be unavailable
- B1004 523545 4 - TROLL SW ACTIVATED
-----
Station change and
Trolling function come to
be unavailable
- B1005 523541 3 - START/STOP SW ACTIVATED
-----
Station change comes to
be unavailable
- P0120 91 3 - MAIN THROTTLE SENSOR H
RANGE
--- -
Station change and
Trolling function come to
be unavailable
- P0120 91 4 - MAIN THROTTLE SENSOR L
RANGE
--- -
- B1020 91 13 - THROTTLE CALIBRATION
INCONSISTENCY
--- -
Station change function
come to be unavailable
- B1043 523768 12 - HELM-ECU EEPROM ERROR
-----
Station change comes to
be unavailable
- B1071 523779 12 - ANALOG CONVERTER
EEPROM ERROR
--- -
- U1214 523781 9 - SW PANEL CAN COM ERROR
-----
Station change comes to
be unavailable.
- B1100 523782 11 - SW PANEL OPTICAL SENSOR
ERROR
-----
- U1207 522039 9 - Can com error Shift Actuator
--- -
Shift is changed to
Neutral position.
- B1061 522040 11 - Shift Actuator failure
--- -
Shift is changed to
Neutral position.
- C1208 522041 9 - Can com error Can-Control Head
--- -
Station change, Synch.
operation,Warmup
operation, and Engine
speed limit mode will be
unavailable.
- C1027 522042 11 - Throttle/Shift sensor warning
Can-Control Head
-----
- C1028 522043 11 - Throttle/Shift sensor failure
Can-Control Head - - -  -
Station change and
Trolling feature will be
unavailable.
- C1029 522044 11 - Trolling sensor failure
Can-Control Head
-----
Trolling feature will be
unavailable.
- B1103 523793 11 - IMMOBILIZER ANTENNA
FAILURE
-----
- C1066 523791 11 - SOFTWARE VERSION ERROR
SW PANEL
-----
LCD DTC SPN FMI
With
FFD
DTC Description
Failsafe Action
Level
1
Level
2
Level
3
Level
4
ENG
Stop
Note
