PRODUCT OVERVIEW
JH Series Operation Manual 21
Meters
Note: The LCD on the instrument panel show hour meter, coolant temperature, display
brightness, oil pressure and battery voltage. See LCD control (hour meter, coolant
temperature, display brightness, oil pressure, battery voltage, alarms) on page 24.
Other indicators in the LCD can be added by display setting. See Selection of the
display setting on page 28.
Coolant temperature and oil pressure display
• B25, C35-Type panels have a digital LCD screen inside the tachometer.
• C35-Type panels have an electric gauge with a needle.
Instrument Function
Tachometer Shows engine rotation speed.
Hour meter Shows number of operating hours. Can be used as a guide for periodic
maintenance checks. The hour meter is located at the bottom of the
tachometer.
Coolant Temperature Gauge Shows the coolant temperature.
Engine Oil Pressure Gauge Shows the engine oil pressure.
Panel Lights When the power switch is pushed, the gauges will illuminate for easier viewing.
