1 Periodic inspections and upkeeps

130

Scheduled maintenance points of the machine (lubrication, filters...)

= Hydraulic oil

= Engine oil

= Hydraulic oil return filter

= Travel gears

= Greasing points

= Air filter

= Fuel filter
