5 Description of the driving position
32
5.9 Cabin
CAUTION
The upper and lower parts of the windscreen can be opened. The opening and closure of
the windscreen must be secured with the safety levers in order to avoid any sudden, un-
planned closure which may cause injuries:
Do not pass our hand or head through the open door or windscreen.
1= Upper windscreen
2= Lower windscreen
3= Side door
WARNING
Place the locking lever(s) in locked position to avoid any unplanned operation of the joys-
ticks when handling the windscreen.
5.9.1 Cab side door
1 = Exterior handle
2= Key
3= Interior handle
a. Opening and closing of the door
From the exterior
• To open the door :
1. Insert the key into the lock.
2. Turn the key anti-clockwise to unlock the door.
3. Pull the exterior handle to open the door.
• To close the door :
Slam the door and turn the key clockwise to lock it.
From the interior
• Pull the interior handle to open the door.
