5 Description of the driving position

5.10 Headlights

WARNING

The headlight becomes very hot when it is operating. Never touch it with your bare hands

before it has cooled down to avoid any risk of burning.

Boom headlamp

Cab headlight (Options )

Canopy type (Options ) Tail light (Options )
