5 Description of the driving position
33
b. Locking the door
•
The door lock is used to hold the door open during the machine operation.
1= Cylindrical lock
2= Handle
To lock the door:
1. Open the door.
2. Push the door against the outer side of the
cabin for engaging the cylindrical lock. (1)
To unlock the door:
1. Pull the handle to disengage the cylindri-
cal lock.(2)
2. Close the door with the handle.
5.9.2 Upper windscreen
Opening of the upper part of the windscreen
1. Grasp the handles (a) and push the levers to the
right and left of the window until you hear a click
for them to unlock.
a = Handle
b = Push
2. Remount the top part of the windscreen and drag
it backwards until it positions itself under the
ceiling.
