5 Description of the driving position
31
Symbol Fuse capacity
Circuit name
K 50A
Preheating relay
L 60A
Enginestop solenoid
Safety relay
M 80A
Starter
Alternator
N 80A
Main circuit
5.8 Ash tray
• Pull the ash tray to open it (1). Close it again
when it is not being used.
• To empty and clean it, press on the two ends
and pull it towards you. To put it back, slide it into
its housing, keeping it flat.
A = Ash tray
WARNING
Do not place any flammable products in the ash tray.
