Gazebo ID Plaque
(Y70800-104)
Dimensions are approximate and are shown to assist in the identification of
parts for assembly. Actual dimensions may be smaller or larger.
Hardware Identification ( )
1pc.
Tie Wrap
Bracket Set (2Pk)
(Y70829-163)
1pc.
Jamb Mount
Bracket Set (10Pk)
(Y70819-157)
1pc.
Tie Centre
Bracket Set (4Pk)
(Y70819-107)
2pc.
Roof Edge Left
(Y01030-152)
2pc.
Ridge Clip
(Y01030-114)
1pc.
Weather Seal - Y70818-171
Ridge Clip (6PK)
1pc.
Corner Bracket
(Y00419-160)
2pc.
Roof Edge Right 75.2
(Y01030-169)
1pc.
Ridge Cap 91
(Y01030-117)
1pc.
Rafter To Beam
Bracket (10Pk)
(Y70819-175)
2pc.
Tie Wrap
Bracket Set (4Pk)
(Y70829-106)
4pc.
Ridge Clip Short 27.5
(Y01030-168)
2pc.
Ridge Cap Short 27.5
(Y01030-167)
1pc.
- Post Mount 9"(8Pk)
(Y70829-122)
6pc.
Main Panel - Y01030-173
1pc.
12 x 14 Pavilion Roof Set
Y70830-173
2pc.
Right Side Panel - Y01030-174
