Step 11: Attach Ridge Caps
Part 2
C: Make sure the Ridge Cap Shorts are ush to the outside edge of the roof then attach each end of the Ridge
Cap to each Ridge Cap Short with two #8 x 3/4” Metal Screws per side. (g. 11.5, 11.6 and 11.7)
Hardware
4 x #8 x 3/4” Sheet Metal Screw
Ridge
Cap
Ridge
Cap
#8 x 3/4” Sheet
Metal Screw
Ridge
Cap Short
Fig. 11.5
Fig. 11.6
Fig. 11.7
x 2
Ridge
Cap Short
Flush
