YASKAWA A1000 Product Replacement Guide

VAN-V17001E<1>, Replacing A1000 crane with CR700
30/44
Refer to the table below for exterior and mounting dimensions.
The table below is shown with the type of A1000 and the 4 digits of CR700 catalog code.
Open Type Enclosure (IP20)
Note: A1000 with the following capacity (HD rating 18.5kW or less, ND rating 22kW or less)
is IP00.
㻌㻌㻌㻌㻌㻌 - CIMR-AA2A0081 and lower
㻌㻌㻌㻌 - CIMR-AA4A0044 and lower
Voltage
class
Dimensions (mm)
A1000 CR700
Model
W H D
W1 H1 D1 t1 Catalog
code
W H D
W1 W2 H1 D2 t1
Three-
phase
200 V
class
0004
140 260
147
122 248
38
5
2003
140 260
176
102 102 248
38
1.6
0006 2005
0008
2008
0010
0012 2011
0018
164
55
2014
211 73
0021 2018
0030
167
2025
0040 2033
0056
180 300 187 160 284 75
2047
180 300 202 140 140 284
68
0069
220 350 197 192 335 78
2060
220 350 227
192
192 335 87
2.3
0081
220 365 197 192 335 78
2075
220 350 227
192
192 335 87
0110
250 400
258
195 385
100
2.3
2088
240 400 280
195
186 375 114
0138
275 450 220 435
2115
255 450 280
170
165 424 114
0169
325 550 283 260 535 110
2145
264 543 335 190 182 516 149
0211 2180
0250
450 705 330 325 680 130 3.2
2215
312 700 420 218 218 659 160
4.5
0312 2283
0360
500 800 350 370 773 130 4.5
2346
440 800 472 370 370 757 218
0415 2415
Three-
phase
400 V
class
0002
140 260
147
122 248
38
5
4002
140 260
176
102 102 248
38
1.6
0004 4003
0005 4005
0007
164
55
4006
211 73
0009 4007
0011 4009
0018
167
4015
0023 4018
0031
180 300 160 284
4024
180 300 202 140 140 284 68
0038 187 75 4031
0044 220 350 197 192 335 78 4039 220 350 227 192 192 335 87
2.3
0058 250 400
258
195 385
100
2.3
4045 220 350 246 192 192 335 106
0072 275 450 220 435 4060 240 400 280 195 186 375 114
0088
325 510 258 260 495 105
4075
255 450 280 170 165 424 114
0103 4091
0139
325 550 283 260 535 110
4112
264 543 335 190 182 516 149
0165 4150
0208 450 705 330 325 680 130 3.2 4180
312 700 420 218 218 659 160 4.50250
500 800 350 370 773 130
4.5
4216
0296 4260
0362 4304
440 800 472 370 370 757 218
4.5
0414 500 950
370
370 923 135 4371
0515
670 1140 440 1110 150
4553
510 1136 480 450 450 1093 220
0675 4605

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
