YASKAWA A1000 Product Replacement Guide

VAN-V17001E<1>, Replacing A1000 crane with CR700
29/44
4. Dimensions and Installation Attachments
4-1. Exterior and Mounting Dimensions
Installation holes are not the same in A1000 and CR700.
The standard model A1000 (200/400V㻌 22kW or less) is compliant for a wall-mount enclosure, while the
standard model CR700 has an open-chassis design (IP20).
An option is required to install CR700 in a wall-mount enclosure.
A UL Type 1 kit needs to be installed to the open-chassis (IP20) CR700. (Refer to Section 4-2)
A1000 CR700
Open Type Enclosure (IP20): Remove the top
cover for compliance
Open Type Enclosure (IP20): Standard model is
compliant
Enclosed wall-mounted type (UL Type 1
enclosure): Standard model is compliant
Enclosed wall-mounted type (UL Type 1 enclosure):
Option required for compliance

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
