YASKAWA TOMPC71061753A YASKAWA AC Drive GA500 Installation and Operation Instruction 25
No.
(Hex.)
Name Description
d2-02 Frequency Reference
Lower Limit
Sets minimum limit for all frequency references. The maximum output
frequency is 100%.
E1-01 Input AC Supply
Voltage
Sets the drive input voltage.
E1-04 Maximum Output
Frequency
Sets the maximum output frequency for the V/f pattern.
E1-05 Maximum Output
Voltage
Sets the maximum output voltage for the V/f pattern.
E1-06 Base Frequency Sets the base frequency for the V/f pattern.
E1-09 Minimum Output
Frequency
Sets the minimum output frequency for the V/f pattern.
E2-01 Motor Rated Current Sets the motor rated current in amps.
E2-11 Motor Rated Power Sets the motor rated output in the units from o1-58 [Motor Power Unit
Selection].
H1-01 - H1-
07
Terminal S1 to S7
Function Selection
Sets functions for MFDI terminals S1 to S7.
H2-01 Term MA/MB-MC
Function Selection
Sets a function for MFDO terminal MA-MC or MB-MC.
H2-02 Term P1-C1 Function
Selection
Sets a function for MFDO terminal P1-C1.
H2-03 Term P2-C2 Function
Selection
Sets a function for MFDO terminal P2-C2.
H3-01 Terminal A1 Signal
Level Select
Sets the input signal level for MFAI terminal A1.
0: 0 to 10V (Lower Limit at 0), 1: 0 V to 10 V (Without Lower Limit)
H3-02 Terminal A1 Function
Selection
Sets a function for MFAI terminal A1.
H3-03
RUN
Terminal A1 Gain
Setting
Sets the gain of the analog signal input to MFAI terminal A1.
H3-04
RUN
Terminal A1 Bias
Setting
Sets the bias of the analog signal input to MFAI terminal A1.
H3-09 Terminal A2 Signal
Level Select
Sets the input signal level for MFAI terminal A2.
0: 0-10V (LowLim=0), 1: 0 V to 10 V (Without Lower Limit), 2: 4 to 20 mA,
3: 0 to 20 mA
H3-10 Terminal A2 Function
Selection
Sets a function for MFAI terminal A2.
H3-11
RUN
Terminal A2 Gain
Setting
Sets the gain of the analog signal input to MFAI terminal A2.
H3-12
RUN
Terminal A2 Bias
Setting
Sets the bias of the analog signal input to MFAI terminal A2.
H3-13 Analog Input
FilterTime Constant
Sets the time constant to apply a primary delay filter to the MFAI terminal.
