YASKAWA CIPR-GA50CB001

10 Attachment
YASKAWA TOMPC71061753A YASKAWA AC Drive GA500 Installation and Operation Instruction 281
■ Three-Phase 400 V Class
Table 10.7 Factory-Recommended Branch Circuit Protection: Three-Phase 400 V Class
Drive Model
Semiconductor
Protection Fuse Rated
Current
Manufacturer: EATON/
Bussmann
4001 FWH-40B
4002 FWH-40B
4004 FWH-50B
4005 FWH-70B
4007 FWH-70B
4009 FWH-90B
4012 FWH-90B
Drive Model
Semiconductor
Protection Fuse Rated
Current
Manufacturer: EATON/
Bussmann
4018 FWH-80B
4023 FWH-100B
4031 FWH-125B
4038 FWH-175B
4044 FWH-200B
4060 FWH-200B
◆ Factory-Recommended Branch Circuit Protection for UL Listing
■ Three-Phase 200 V Class
Table 10.8 Factory-Recommended Branch Circuit Protection: Three-Phase 200 V Class
Drive Model
Maximum Applicable Motor
Output
kW (HP)
Time Delay
Fuse
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
ND HD
Class J, CC,
and T Fuse
Rated Current
A
Model
Input Rated
Current
A
2001 0.18 (1/6) 0.1 (1/6) 3 FWH-25A14F 25
2002 0.37 (1/4) 0.25 (1/4) 6 FWH-25A14F 25
2004 0.75 (3/4) 0.55 (1/2) 6 FWH-25A14F 25
2006 1.1 (1)
0.75 (1) 10 FWH-25A14F 25
2010 2.2 (3) 1.5 (2) 20 FWH-70B 70
2012 3.0 (3) 2.2 (3) 25 FWH-70B 70
2021 5.5 (5) 4.0 (5) 40 FWH-90B 90
2030 7.5 (7.5) 5.5 (7.5) - FWH-100B 100
2042 11 (10) 7.5 (10) - FWH-150B 150
2056 15 (15) 11 (15) - FWH-200B 200
2070 18.5 (20) 15 (20) - FWH-200B 200
2082 22 (25) 18.5 (25) - FWH-225A 225
