YASKAWA CIPR-GA50CB001

10 Attachment
282 YASKAWA TOMPC71061753A YASKAWA AC Drive GA500 Installation and Operation Instruction
■ Single-Phase 200 V Class
Table 10.9 Factory-Recommended Branch Circuit Protection: Single-Phase 200 V Class
Drive Model
Maximum Applicable Motor
Output
kW (HP)
Time Delay
Fuse
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
ND HD
Class J, T, and
CC Fuse
Rated Current
A
Model
Input Rated
Current
A
B001 0.18 (1/6) 0.1 (1/6) 3 FWH-25A14F 25
B002 0.37 (1/4) 0.25 (1/4) 6 FWH-25A14F 25
B004 0.75 (3/4) 0.55 (1/2) 10 FWH-60B 60
B006 1.1 (1.5) 1.1 (1) 15 FWH-80B 80
B010 2.2 (3) 1.5 (2) 25 FWH-100B 100
B012 3.0 (3) 2.2 (3) 30 FWH-125B 125
B018 - 4.0 (5) - FWH-150B 150
■ Three-Phase 400 V Class
Table 10.10 Factory-Recommended Branch Circuit Protection: Three-Phase 400 V Class
Drive Model
Maximum Applicable Motor
Output
kW (HP)
Time Delay
Fuse
Semiconductor Protection Fuse
Rated Current
Manufacturer: EATON/Bussmann
ND HD
Class J, CC,
and T Fuse
Rated Current
A
Model
Input Rated
Current
A
4001 0.37 (1/2) 0.37 (1/2) 3 FWH-40B 40
4002 0.75 (1) 0.55 (3/4) 6 FWH-40B 40
4004 1.5 (2) 1.1 (2) 10 FWH-50B 50
4005 2.2 (3) 1.5 (3) 10 FWH-70B 70
4007 3.0 (4) 2.2 (3) 15 FWH-70B 70
4009 4.0 (5) 3.0 (4) 20 FWH-90B 90
4012 5.5 (7.5) 4.0 (5) 25 FWH-90B 90
4018 7.5 (10) 5.5 (10) - FWH-80B 80
4023 11.0 (15) 7.5 (10) - FWH-100B 100
4031 15.0 (20) 11.0 (15) - FWH-125B 125
4038 18.5 (25) 15.0 (20) - FWH-175B 175
