10 Attachment
298 YASKAWA TOMPC71061753A YASKAWA AC Drive GA500 Installation and Operation Instruction
Model Terminal
Recommen
ded Gauge
AWG, kcmil
Applicable
Gauge
AWG, kcmil
Wire
Stripping
Length
*1
mm
Terminal Screw
Tightening
Torque
N∙m (in∙lb)
Size Shape
2021
R/L1, S/L2, T/L3 8 14 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 10 14 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 8 14 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
B1, B2 14 14 - 10 10 M4
1.5 - 1.7
(13.5 - 15)
8 14 - 8 - M4
1.2 - 1.5
(10.6 - 13.3)
2030
R/L1, S/L2, T/L3 8 12 - 6 10 M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 8 12 - 6 10 M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 6 12 - 6 10 M4
1.5 - 1.7
(13.5 - 15)
B1, B2 12 12 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
8 10 - 6 - M5
2.0 - 2.5
(17.7 - 22.1)
2042
R/L1, S/L2, T/L3 6 12 - 6 10 M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 6 12 - 6 10 M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 4 10 - 2 18 M5
• ≤ AWG 10
2.3 - 2.5
(19.8 - 22)
• AWG 8 ≤
4.1 - 4.5
(36 - 40)
B1, B2 10 14 - 6 10 M4
1.5 - 1.7
(13.5 - 15)
6 10 - 6 - M5
2.0 - 2.5
(17.7 - 22.1)
