YASKAWA Drive-V1000 User Manual

YASKAWA TOBP C730600 29A V1000 Option LCD Operator Installation Manual 3
Table of Contents
1 PREFACE AND SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 PRODUCT OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
3 RECEIVING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 LCD OPERATOR OPTION COMPONENTS . . . . . . . . . . . . .12
5 INSTALLATION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . .20
6 BASIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
7 RELATED PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . . .33
8 LCD OPERATOR OPTION FAULT DIAGNOSTICS. . . . . . .35
9 SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

YASKAWA Drive-V1000 Specifications

General

Series	V1000
Output Current	Varies by model (refer to specific model datasheet)
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Humidity	95% RH or less (non-condensing)
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Ground Fault, Short Circuit
Communication	Modbus RTU, PROFIBUS-DP, DeviceNet, EtherNet/IP
Braking Unit	Built-in or External (optional)
Input Voltage	3-Phase 200-240 VAC ±10% 50/60 Hz, 3-Phase 380-480 VAC ±10% 50/60 Hz
Output Voltage	0 to Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
