7 Related Parameters
7 Related Parameters
Parameters related to the use of the LCD Operator Option are listed below. Set these
parameters as needed for the application.
Table 11 Related Darameters
No. Name Description Default
A1-00
Language
Selection
Language selection for the LCD Operator Option.
This parameter is not reset when the drive is initialized by
parameter A1-03.
0: English
1: Japanese
2: German
3: French
4: Italian
5: Spanish
6: Portuguese
7: Chinese
0
b1-01
Frequency
Reference
Selection 1
Selects the source of the frequency reference.
0: Operator -Digital preset speed d1-01 to d1-17
1: Terminals - Analog input terminal A1 or A2
2: MEMOBUS/Modbus serial communications
3: Option PCB
4: Pulse Input (Terminal RP)
1
b1-02
Run
Command
Selection 1
Selects the run command input source.
0: Operator -RUN and STOP keys on the LCD Operator Option
1: Digital input terminals S1 to S7
2: MEMOBUS/Modbus serial communications
3: Option PCB
1
b1-15
Frequency
Reference 2
Selects the frequency reference input source.
0: Operator - Digital preset speed d1-01 to d1-17
1: Terminals - Analog input terminal A1 or A2
2: MEMOBUS/Modbus serial communications
3: Option PCB
4: Pulse Input (Terminal RP)
0
b1-16
Run
Command
Source 2
Selects the Run command input source.
0: Operator - RUN and STOP keys on the LCD Operator Option
1: Digital input terminals S1 to S7
2: MEMOBUS/Modbus serial communications
3: Option PCB
0

YASKAWA Drive-V1000 Specifications

General

Series	V1000
Output Current	Varies by model (refer to specific model datasheet)
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Humidity	95% RH or less (non-condensing)
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Ground Fault, Short Circuit
Communication	Modbus RTU, PROFIBUS-DP, DeviceNet, EtherNet/IP
Braking Unit	Built-in or External (optional)
Input Voltage	3-Phase 200-240 VAC ±10% 50/60 Hz, 3-Phase 380-480 VAC ±10% 50/60 Hz
Output Voltage	0 to Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
