YASK AWA TOBP C730600 29A V1000 Option LCD Operator Installation Manual 37
9 Specifications
9 Specifications
Table 13 LCD Operator Option Specifications
Model JVOP-180
Connector RJ-45
Power Supply Powered from the drive (DC +5 V ±5%)
Operating
Temperature
-10 to +50 °C
<1>
<1> The LCD display may respond more slowly if the ambient temperature falls below freezing. Higher temperatures
can also shorten the performance life of the LCD display.
Humidity up to 95% RH (no condensation)
Storage Temperature
-20 to +60 °C
(allowed for short-term transport of the product)
Area of Use Indoor (free of corrosive gas, airborne particles, etc.)
Altitude Up to 1000 m
Shock
10 to 20 Hz : 9.8 m/s
2
20 to 55 Hz : 5.9 m/s
2
Read Function
Limitation
Estimated 100,000 times

YASKAWA Drive-V1000 Specifications

General

Series	V1000
Output Current	Varies by model (refer to specific model datasheet)
Operating Temperature	-10°C to +50°C (14°F to 122°F)
Humidity	95% RH or less (non-condensing)
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Ground Fault, Short Circuit
Communication	Modbus RTU, PROFIBUS-DP, DeviceNet, EtherNet/IP
Braking Unit	Built-in or External (optional)
Input Voltage	3-Phase 200-240 VAC ±10% 50/60 Hz, 3-Phase 380-480 VAC ±10% 50/60 Hz
Output Voltage	0 to Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
