1 Preface and Safety
YASK AWA TOBP C730600 29A V1000 Option LCD Operator Installation Manual 5
◆ Applicable Documentation
The following manuals are available for the JVOP-180 LCD Operator Option:
For the drive setup, refer to the drive Quick-Start Guide or Technical Manual.
◆ Terms
LCD Operator
V1000 Option LCD Operator Installation Manual
Read this manual first.
The installation manual is packaged with the LCD Operator Option and
contains a basic overview of wiring, settings, functions, and fault
diagnoses.
Yaskawa Drive
Yaskawa AC Drive-V1000
Technical Manual
To obtain instruction manuals for Yaskawa
products access these sites:
U.S.: http://www.yaskawa.com
Europe: http://www.yaskawa.eu.com
Japan: https://www.e-mechatronics.com
Other areas: contact a Yaskawa representative.
For questions, contact the local Yaskawa sales
office or the nearest Yaskawa representative.
Yaskawa AC Drive-V1000
Quick Start Guide
Drive: Yaskawa AC Drive -V1000 Series.
LCD Operator Option: JVOP-180 LCD Operator unit for the Yaskawa V1000 drive.
Note: Indicates a supplement or precaution that does not cause drive damage.
≥ 1012:
Indicates a drive feature or function that is only available in drive software
version 1012 or greater.
LED: Light emitting diode.
LCD: Liquid crystal display.
STOP
(
Hz
)
(
Hz
)
(
A
)
(
V
)
:
:
:
:
:
:
:
:
:
:
V1000
周波数指令
正転逆転選択
出力周波数
出力電流
出力電圧
モニタ
ベリファイ
セットアップ
パラメータ設定
オートチューニング
据え付け、運転の前には必ず取扱説明書を読むこと。
通電中および電源遮断後
5
分以内はフロントカバーを
外さないこと。
400V
級インバータの場合は、電源の中性点が接地
されていることを確認すること。（ 対応）
けが、感電のおそれがあります。
危 険
Read manual before installing.
Wait 5 minutes for capacitor discharge after
disconnecting power supply.
To conform to requirements, make sure
to ground the supply neutral for 400V class.
Risk of electric shock.
WARNING
