YASKAWA F7 User Manual

Spare Parts F - 3
F7 Primary Spare Parts - 480Vac
Table F.2 480Vac F7 Primary Spare Parts
Drive Model
CIMR-F7U
Hp
Power PCB
(3PCB)
Gate Drive PCB
(3PCB)
Control PCB
(1PCB)
Terminal PCB
(2PCB)
Diode Module
40P4
0.5/0.75
ETP617082 N/A E TC618390-S3020 ETC618410 Inside the Power Module
40P7
1
ETP617082 N/A ETC618390-S3020 ETC618410 Inside the Power Module
41P5
1.5/2
ETP617092 N/A ETC618390-S3020 ETC618410 Inside the Power Module
42P2
3
ETP617102 N/A ETC618390-S3020 ETC618410 Inside the Power Module
43P7
5
ETP617112 N/A ETC618390-S3020 ETC618410 Inside the Power Module
44P0
-
ETP617122 N/A ETC618390-S3020 ETC618410 Inside the Power Module
45P5
7.5
ETP617132 N/A ETC618390-S3020 ETC618410 Inside the Power Module
47P5
10
ETP617142 N/A ETC618390-S3020 ETC618410 Inside the Power Module
4011
15
ETP617152 N/A ETC618390-S3020 ETC618410 Inside the Power Module
4015
20
ETP617162 N/A ETC618390-S3020 ETC618410 SID003112 (D1)
4018
25
ETP617172 N/A ETC618390-S3020 ETC618410 SID000605 (D1)
4022
30
N/A ETC617141 ETC618390-S3020 ETC618410 SID003112 (D1,D2)
4030
40
N/A ETC617151 ETC618390-S3020 ETC618410 SID003112 (D1,D2)
4037
50
N/A ETC617161 ETC618390-S3020 ETC618410 SID003112 (D1,D2)
4045
60
N/A ETC617171 ETC618390-S3020 ETC618410 SID000605 (D1,D2)
4055
75
N/A ETC617181 ETC618390-S3020 ETC618410 SID000605 (D1,D2)
4075
100
N/A ETC617190 ETC618390-S3020 ETC618410 SID003117 (D1,D2)
4090
125/150
N/A ETC617200 ETC618390-S3020 ETC618410 SID003117 (D1,D2)
4110
-
N/A ETC617210 ETC618390-S3020 ETC618410 SID003109 (D1-D6)
4132
200
N/A ETC617220 ETC618390-S3020 ETC618410 SID003118 (D1-D6)
4160
250
N/A ETC617230 ETC618390-S3020 ETC618410 SID003119 (D1-D6)
4185
300
N/A ETC617240 ETC618390-S3020 ETC618410 SID003119 (D1-D6)
4220
350/400
N/A ETC617250 ETC618390-S3020 ETC618410 SID003131 (D1-D6)
4300
450/500+
N/A ETC617260 ETC618390-S3020 ETC618410 SID003119(D1-D12)
Table F.2 480Vac F7 Primary Spare Parts (Continued)
Drive Model
CIMR-F7U
Hp Power Module Transistor Module DC Bus Fuse Heat Sink Fan Internal Fan
40P4
0.5/0.75
STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
40P7
1
STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
41P5
1.5/2
STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
42P2
3
STR001298 (Q1) N/A FU-002029 (F1) FAN001066 (B1) N/A
43P7
5
STR001300 (Q1) N/A FU-002031 (F1) FAN001066 (B1) N/A
44P0
-
N/A N/A FU-002031 (F1) FAN001066 (B1) N/A
45P5
7.5
STR001302 (Q1) N/A FU-002031 (F1) FAN001066 (B1) N/A
47P5
10
STR001279 (Q1) N/A FU-002032 (F1) FAN001066 (B1,B2) N/A
4011
15
N/A STR001280 (Q1) FU-002037 (F1) FAN001066 (B1,B2) FAN001043 (B3)
4015
20
N/A STR001318 (Q1) FU-002038 (F1) FAN001065 (B1,B2) N/A
4018
25
N/A STR001318 (Q1) FU-002038 (F1) FAN001065 (B1,B2) FAN001043 (B3)
4022
30
N/A STR001324 (Q1) FU-002038 (F1) FAN001039 (B1,B2) N/A
4030
40
N/A STR001324 (Q1) FU-002039 (F1) FAN001039 (B1,B2) N/A
4037
50
N/A STR001316 (Q1-Q3) FU-002040 (F1) FAN001044 (B1,B2) N/A
4045
60
N/A STR001317 (Q1-Q3) FU-002040 (F1) FAN001044 (B1,B2) N/A
4055
75
N/A STR001317 (Q1-Q3) FU-002101 (F1) FAN001044 (B1,B2) N/A
4075
100
N/A STR001294 (Q1-Q3) FU-002112 (F1) FAN001052 (B1,B2) FAN001054 (B4)
4090
125/150
N/A STR001336 (Q1-Q6) FU-002113 (F1) FAN001052 (B1,B2) FAN001054 (B4)
4110
-
N/A STR001336 (Q1-Q6) FU-002114 (F1) FAN001056 (B1,B2) FAN001054 (B4)
4132
200
N/A STR001322 (Q1-Q6) FU-000894 (F1) FAN001056 (B1,B2) FAN001054 (B4)
4160
250
N/A STR001322 (Q1-Q3) FU-000895 (F1) FAN001056 (B1,B2) FAN001054 (B4)
4185
300
N/A STR001339 (Q1-Q12) FU-000895 (F1) FAN001056 (B1-B4) FAN001054 (B6,B7)
4220
350/400
N/A STR001341 (Q1-Q12) FU-002116 (F1) FAN001056 (B1-B4) FAN001054 (B6,B7)
4300
450/500+
N/A STR001342 (Q1-Q12) FU-002117 (F1) FAN001082 (B1-B5) FAN001054 (B6,B7)
